Machine Bay / Gear machines / Roll forming / thread rolling machine
Gear machines
NC Precision Roll Forming Machine
Details being confirmed with supplier
Price on enquiry
Currently in Taichung, Taiwan. Delivered anywhere in Australia. Freight quoted on enquiry.
Link copied.
Machine
| Title | NC Precision Roll Forming Machine |
|---|---|
| Maker | NACHI |
| Model | PFS-1120FHNC |
| Family | Gear machines |
| Type | Roll forming / thread rolling machine |
| Location | Taichung, Taiwan |
| Price | Price on enquiry |
| Module | 1.67 |
Not yet confirmed: voltage, year and condition.
Specification
| Max Rolling Dia | 55 |
|---|---|
| Max Rolling Module | 1.67 |
| Max Rack Holder Width | 160 |
| Main Motor | 50HP |
| Max Rack Stroke | 1350mm |
| Forming Rack | 13" |
Specification text
Max Rolling Dia55, Max Rolling Module1.67, Max Rack Holder Width 160, Main Motor 50HP, Max Rack Stroke 1350mm, Forming Rack 13", 14", 28", 44"
