Machine Bay / Grinding machines / Cylindrical grinder (incl. universal, angular, roll)

Grinding machines

Cylindrical Grinder

Details being confirmed with supplier

Price on enquiry

Currently in Taichung, Taiwan. Delivered anywhere in Australia. Freight quoted on enquiry.

Request a quote

5 photos

Machine

TitleCylindrical Grinder
MakerSWITZERLAND TSCHUDIN
ModelHTG-610
FamilyGrinding machines
TypeCylindrical grinder (incl. universal, angular, roll)
Weight1,800 kg
LocationTaichung, Taiwan
PricePrice on enquiry

Not yet confirmed: voltage, year and condition.

Specification

Centre height100
Distance between centres600φ
Max longitudinal travel620
Grinding wheel350
Bore1270
wheel width50
Spinder taper MT4
workpiece spinder head360°
Table angular displacement7°
Spinder rpm65~500rpm
chine weight1,800 kg

Specification text

Centre height 100, Distance between centres 600φ, Max longi tudinat travel 620, Grinding wheel 350, Bore 1270, wheel width 50, Spinder taper MT4, workpiece spinder head 360°, Table angular displace ment 7°, Spinder rpm 65~500rpm, chine weight 1,800 kg
