Vertical CNC Hob Re-Sharpening Machine

Details being confirmed with supplier

Price on enquiry

Currently in Taichung, Taiwan. Delivered anywhere in Australia. Freight quoted on enquiry.

Request a quote

4 photos

Machine

TitleVertical CNC Hob Re-Sharpening Machine
MakerPROTO (M.I.T)
ModelSV-150 TYPE
FamilyGear machines
TypeHob / cutter / broach sharpener
Weight1,500 kg
LocationTaichung, Taiwan
PricePrice on enquiry

Not yet confirmed: voltage, year and condition.

Specification

Max. hob diameter150mm
Min. hob diameter10mm
Max. hob axial slide travel300mm
Max. hob length250mm
Grinding wheel daimeterØ190mm
Grinding wheel speed4200rpm
Number of gashes1/999
Max. moduleM10
Sharpening hob typeHSS / TiN / Carbide
Total power consumption4KVA
Weight1,500 kg

Specification text

Max. hob diameter: 150mm, Min. hob diameter: 10mm, Max. hob axial slide travel: 300mm, Max. hob length: 250mm, Grinding wheel daimeter: Ø190mm, Grinding wheel speed: 4200rpm, Number of gashes: 1/999, Max. module: M10, Sharpening hob type: HSS / TiN / Carbide, Total power consumption: 4KVA, Voltage: 3ψ / 220V Length x Width x Height: L: 1400mm/W: 800mm/H: 1800mm, Weight: 1,500 kg
